Pi Voltmeter

CM4 + ADS1115 (2 channels, single-ended A0/A1) + Adafruit 128x64 OLED bonnet.

Features

• Live value of both channels, converted by a selectable formula.
• Formula files: <name>.txt, line 1 = unit, line 2 = expression in V (e.g. degC / V * 100). Functions: sqrt, log, ln, log10, log2, exp, abs, sin, cos, tan, asin, acos, atan, pow, min, max, round; constants pi, e. Invalid files are skipped.
• On-screen menu: A or joystick press opens it, up/down selects, left/right changes a value, B goes back. Items: formula per channel, N (seconds between timestamped records in the CSV / future DB), ADC range, display refresh period, USB logging. Settings persist in settings.json.
• Plug in a USB stick: valid formulas/*.txt on it are copied to the Pi. With USB log: ON, readings are written to voltmeter_logs/log_<time>.csv on the stick (new file per insertion; header + one row per reading). Screen shows REC while logging.

Configuration

• config.yaml (default ~/voltmeter/config.yaml, or --config): device-level setup, read once at startup. Covers ADC/OLED I2C bus and address, button GPIO pins, USB mount roots and the formula/log folder names on the stick, plus the database: section for TigerData publishing. Every key is optional; see config.yaml for defaults. Bad values stop startup with a clear message; unknown keys are warned about and ignored.
• settings.json: user preferences changed from the on-screen menu (not for hand editing).

TigerData (Grafana dashboard backend)

1. Create a service at tigerdata.com and note its host, port, dbname and user.
2. In config.yaml set database.enabled: true and database.host (plus the other fields).
3. Install the driver: pip install '.[tigerdata]'.
4. Provide the password via environment, never in the file: export VOLTMETER_DB_PASSWORD=... (for systemd, put VOLTMETER_DB_PASSWORD=... in /etc/voltmeter.env, chmod 600; the unit loads it if present).

The table (readings by default) is created automatically as a hypertable, one row per channel per record (every N seconds): time, device_id, channel, volts, unit, formula. volts is the input voltage (after the divider); the formula is a label only, so apply it in the query (e.g. 10 ^ ((volts - 7.75)/0.75 - 0.125)). device_id defaults to the hostname, so several devices can share a table. In Grafana add a PostgreSQL/TimescaleDB data source and query, e.g.:

SELECT time, volts FROM readings
WHERE device_id = 'pi-1' AND channel = 0 AND $__timeFilter(time) ORDER BY time

Uploads run on a background thread in batches. If the network drops, rows buffer in memory (up to max_buffer, oldest dropped beyond) and are sent on reconnect; duplicates are impossible on retry. The buffer is not persisted, so a power loss while offline loses the unsent rows (the USB CSV is the durable copy).

Pi setup

sudo raspi-config nonint do_i2c 0        # enable I2C
python3 -m venv ~/voltmeter-venv && ~/voltmeter-venv/bin/pip install '.[pi]'
mkdir -p ~/voltmeter/formulas && cp formulas/*.txt ~/voltmeter/formulas/ && cp config.yaml ~/voltmeter/
# edit User/paths in deploy/voltmeter.service if your user is not "admin"
sudo cp deploy/voltmeter.service /etc/systemd/system/ && sudo systemctl daemon-reload && sudo systemctl enable --now voltmeter

• Defaults: ADS1115 0x48, OLED 0x3C; change them in config.yaml.
• Input dividers: set device.adc.ch0_divider / ch1_divider (r_top, r_bottom) if a resistor divider sits ahead of an ADC input. Readings, formulas and logs then see the real input voltage (pin voltage × (r_top + r_bottom) / r_bottom). The menu "Range" is the ADC pin range, not the input range.
• USB must be auto-mounted under a usb.mount_roots folder (/media, /mnt, /run/media by default) (Pi OS desktop does this; on Lite install usbmount or udisks2+udiskie). Remove the stick before unplugging to avoid data loss; the CSV is flushed every row and fsynced every second.
• Keep inputs within 0..VDD (+0.3 V) of the ADS1115.

Develop without hardware

pip install -e '.[dev]' && pytest
voltmeter --sim --home /tmp/vm      # writes the screen to /tmp/voltmeter.png

Layout / extending

• adc.py ADC backends · formulas.py · settings.py · usb.py · ui.py (renders a PIL image) · hardware.py (OLED/buttons) · app.py (loop).
• Every reading is a Reading object fanned out to sinks (sinks.py). For TigerData/Grafana, add a class with write(reading) / close() (batch + retry in a background thread so the sampling loop never blocks) and register it with App.add_sink(...). Grafana reads from the TigerData (Postgres) table.

Web dashboard (Vercel)

web/ is a FastAPI app that shows the latest value of every channel, refreshed every 2 s (/ is the page, /api/latest the JSON). It reads the readings table and applies each row's stored formula name to its volts using the same formulas/*.txt and parser as the Pi.

1. In psql (as the admin user) run db/readonly_role.sql after setting a password; the web app gets a SELECT-only role, never the admin or Pi credentials.
2. Run locally: DATABASE_URL='postgres://voltmeter_web:PASSWORD@HOST:PORT/tsdb?sslmode=require' uvicorn app:app --reload from web/ (needs pip install '.[web]').
3. Optional but recommended: as admin run db/timescale_setup.sql (continuous aggregate readings_1m, compression after 1 day, 90-day retention). Then set READINGS_AGG=readings_1m; history ranges of 6 h and longer read the aggregate instead of raw rows.
4. Deploy: import the repo in Vercel with Root Directory web, framework "Other", and add DATABASE_URL (+ READINGS_AGG) as environment variables. Every push to main redeploys. web/ must be self-contained, so it holds copies of voltmeter/formulas.py and formulas/*.txt; after editing the originals run cp voltmeter/formulas.py web/voltmeter/ && cp formulas/*.txt web/formulas/ (a test fails if they drift). GitHub Actions (.github/workflows/ci.yml) runs the tests.

Public demo: deploy a second Vercel project from the same repo (Root Directory web) with only DEMO_MODE=1 set and no DATABASE_URL. It serves simulated demo-cryo readings and cannot reach your database. Themes: / is a clean instrument-panel look; /neon, /neo (neo-brutalist) and /nge (retrofuturist military) and /98 (Windows 98 via 98.css) are easter eggs. Graph values are the average of each time bucket's converted readings: formulas are translated to SQL and applied to every row before averaging, so a non-linear formula (e.g. the pressure one) is not reduced to a geometric mean. The readings_1m aggregate stores mean volts, so ranges of 6 h or more use it only for formulas that are linear in V; other formulas read raw rows. Formulas that can't be translated to SQL (%, //, two-argument log) fall back to converting the mean volts. The page has a history graph (1m to 24h, per device/channel, value or volts, linear or log). Channels older than STALE_AFTER_S (30 s) are dimmed and marked stale. If a row names a formula that is not in formulas/, the page falls back to showing volts.
